The second generation of scissors lifts has been improved in various aspects, such as performance and design, which makes them even more convenient to maintain and safer to operate.
● Large lower control panel
● Entire range designed for Indoor and outdoor use
● Universal key components
● More convenient to maintain
● Optional lithium battery for the entire product range
| Models | S0808EⅡ | S2632EⅡ |
| Measurements | ||
| Work Height Max. | 9.8/8m (in/out) | 32'2''/26'3'' (in/out) |
| A-Platform Height-Raised | 7.8/6m (in/out) | 25'7''/19'8'' (in/out) |
| B-Platform Length | 2.26m | 7'5'' |
| C-Platform Width | 0.79m | 2'7'' |
| D-Overall Length | 2.44m | 8' |
| E-Overall Width | 0.83m | 2'9'' |
| F-Overall Height-Guardrails Up | 2.28m | 7'6'' |
| G-Overall Height-Guardrails Down | 1.9m | 6'3'' |
| H-Extension Deck | 0.9m | 2'11'' |
| I-Wheelbase | 1.85m | 6'1'' |
| Ground Clearance(Stowed/Raised) | 100/20mm | 4''/1'' |
| Productivity | ||
| Max. Platform Occupants | 2 (in) /1 (out) | |
| Platform Capacity | 230kg | 510 lbs |
| Platform Capacity-Extension Deck | 120kg | 265 lbs |
| Drive Height | Full Height | |
| Gradeability-Stowed | 25% | |
| Min. Turning Radius | 2.2m | 7'3'' |
| Raise/Lower Speed | 31s /40s | |
| Brakes | Rear-wheel Brake | |
| Drive Mode | 4×2 | |
| Tire Type | Solid Non-marking | |
| Tire Size | 380*130mm | 15''x5'' |
| Ground Pressure, Tyres | 1002 kPa | 145.3 psi |
| Power | ||
| Power Source | 24V (4x6V) 225Ah, FLA | |
| Power Source (Lithium Battery) | 24V 160Ah | |
| Hydraulic System | ||
| Hydraulic Oil Capacity | 13L | 3.4gal |
| Weight | ||
| Machine Weight(CE/ANSI) | 2200kg | 4850 lbs |
STANDARD FEATURES：
Indoor and outdoor applications
Proportional control
Foldable guardrail
Emergency stop device
Manual brake release
Emergency descent
Swing-out component tray
Pothole guard
Self-lock entry gate
Tilt alarm with lift cut-out
Overload sensing system
Descent alarm with flashing beacon
All motions alarm
Full-height drive
Intelligent diagnostic system
Solid non-marking tires
OPTIONAL：
AC power to platform
Anti-collision protection
Biodegradable hydraulic oil
Maintenance-free battery
Voice alarm system
Telematics
