l The four-wheel-drive system provides outstanding rough terrain capability, smooth transmission, and comfortable driving.
l Equipped with a Permanent Magnet Synchronous Motor (PMSM), integrating the motor and controller into a single (3-in-1), maintenance-free unit that significantly boosts efficiency while reducing wear and maintenance costs.
l Proportional lift and drive controls deliver smoother maneuvering, precise positioning and comfortable operation.
l Remote software upgrades, parameter adjustments, and remote online diagnosis through telematics.
l The intelligent self-diagnosis function enables quick troubleshooting at the working site.
| MODELS | A14JE-2 | A45JE-2 |
| Measurements | Metric | Imperial |
| Work Height Max. | 16m | 52'6" |
| Platform Height Max. | 14m | 45'11" |
| Horizontal Outreach Max. | 7.73m | 25'4" |
| Up and Over Height | 7.26m | 23'10" |
| Platform Length | 1.83m | 6' |
| Platform Width | 0.76m | 2'6" |
| A- Length-Stowed | 6.66m | 21'10" |
| Length-Transport(jib tucked) | 5.58m | 18'4" |
| B- Overall Width | 1.8m | 5'11" |
| C- Height-Stowed | 1.96m | 6'5" |
| Height-Transport | 2.5m | 8'2" |
| D-Wheelbase | 2.03m | 6'8" |
| E-Ground Clearance | 0.18m | 7" |
| PRODUCTIVITY | ||
| Platform Capacity(unrestricted) | 230kg | 507 lbs |
| Platform Capacity(restricted) | 350kg | 772 lbs |
| Max. Platform Occupants | 2（unrestricted）/3(restricted) | |
| Turntable Rotation | 355° | |
| Drive Speed-Stowed | 5km/h | 3.1mph |
| Drive Speed-Raised | 0.8km/h | 0.5mph |
| Gradeability | 30% | |
| Max. Wind Speed | 12.5m/s | 28mph |
| Turning Radius-Inside | 2.14m | 7' |
| Turning Radius-Outside | 4.3m | 14'1" |
| Max. Slope | 5°/5° | |
| Tire Type | Foam-filled Non-marking | |
| Tire Models | 240/55D17.5 | |
| Ground Pressure, Tyres | 409.8 kPa | 59.4 psi |
| POWER | ||
| Power Source | 80V 125Ah | |
| HYDRAULIC SYSTEM | ||
| Hydraulic Oil Volume | 30L | 7.9 gal |
| WEIGHT | ||
| Machine Weight | 7100kg | 15653 lbs |
STANDARD FEATURES
Auto-leveling platform
Hydraulic rotating platform 180°
Full proportional joystick control
Descent alarm
Flashing beacons
Horn/Hour meter
Over-tilt protection system
Emergency stop button
Intelligent self-diagnosis function
Cylinder bellows
OTA remote upgrade
Dustproof components
Over-head anti-collision protection
Platform tool box
OPTIONAL
AC power to platform
Platform work light
Half-height mesh platform
Platform auxiliary guardrail
Platform storage rack
