● Li-battery powered provides quiet and zero emission.
● 260/350kg (573 /772 Ibs) dual-capacity design, 1.83m (6') triple entry platform.
● Oscillating, full-time floating axels allow the wheels to grip to the ground when driving on hard, uneven terrain.
● Integrated four-wheel-drive system provides strong power, smooth transmission, and 45% gradeability.
● Equipped with three steering modes and one-touch wheel alignment.
● Proportional lift and drive controls deliver smoother maneuvering, precise positioning and comfortable operation.
| Models | AR18JE | AR60JE |
| Measurements | Metric | US |
| Work Height Max. | 20.12m | 66' |
| Platform Height(Raised) | 18.12m | 59'5'' |
| Horizontal Outreach | 10.9m | 35'9'' |
| Up and Over Height | 7.7m | 25'3'' |
| Platform Length | 1.83m | 6' |
| Platform Width | 0.76m | 2'6'' |
| Platform Capacity | 260/350kg | 573/772 lbs |
| A-Stowed Length | 8.42m | 27'7'' |
| Length-Transport (jib tucked） | 6.42m | 21'1" |
| B-Overall Width | 2.5m | 8'2'' |
| C-Stowed Height | 2.47m | 8'1'' |
| Height-Transport | 3.07m | 10'1'' |
| D-Wheelbase | 2.51m | 8'3'' |
| E-Ground Clearance | 0.4m | 1'4'' |
| Productivity | ||
| Max. Platform Occupancy | 2(unrestricted) / 3(restricted) | |
| Turntable Rotation | 360° | 360° |
| Drive Speed-Stowed | 5km/h | 3.1mph |
| Drive Speed-Raised | 0.8km/h | 0.5mph |
| Gradeability | 45% | 45% |
| Max. Wind Speed | 12.5m/s | 28mph |
| Turning Radius-Inside | 1.9m | 6'3'' |
| Turning Radius-Outside | 3.9m | 12'10'' |
| Max.Slope | 4°/4° | 4°/4° |
| Tire Type | Foam-filled non-marking | |
| Tire Size | 355/55D 625 | |
| Power | ||
| Power Source | 80V 228Ah | |
| Hydraulic System | ||
| Hydraulic Oil Volume | 90L | 23.8gal |
| Weight | ||
| Machine Weight (CE/ANSI) | 8150kg | 17968 lbs |
Standard features
Proportional control
Horn/Hour meter
Emergency stop device
Auto-leveling platform
Anti-collision protection
Over tilt protection system
Platform control cover
Overload sensing system
Intelligent diagnostic system
Full-height drive
Flashing beacons
Cylinder bellows
Platform tool box
Oscillating axle
Telematics connector
Foam-filled non-marking tires
Optional
Telematics
AC power to platform
Foam-filled tires
Solid non-marking tires
Solid tires
Half-height mesh platform
Auxiliary rail
Biodegradable hydraulic oil
