l The four-wheel-drive system provides outstanding rough terrain capability, smooth transmission, and comfortable driving.
l Equipped with a Permanent Magnet Synchronous Motor (PMSM), integrating the motor and controller into a single (3-in-1), maintenance-free unit that significantly boosts efficiency while reducing wear and maintenance costs.
l Proportional lift and drive controls deliver smoother maneuvering, precise positioning and comfortable operation.
l Remote software upgrades, parameter adjustments, and remote online diagnosis through telematics.
l The intelligent self-diagnosis function enables quick troubleshooting at the working site.
| MODELS | AR20J-2 | AR65J-2 |
| Measurements | Metric | Imperial |
| Work Height Max. | 21.58m | 70'10" |
| Platform Height Max. | 19.58m | 64'3" |
| Horizontal Outreach Max. | 11.87m | 38'11" |
| Up and Over Height | 8.19m | 26'10" |
| Platform Length | 2.44m | 8' |
| Platform Width | 0.9m | 2'11" |
| A- Length-Stowed | 9.42m | 30'11" |
| Length-Transport(jib tucked) | 7.63m | 25' |
| B- Overall Width | 2.5m | 8'2" |
| C- Height-Stowed | 2.46m | 8'1" |
| Height-Transport | 2.96m | 9'9" |
| D-Wheelbase | 2.51m | 8'3" |
| E-Ground Clearance | 0.4m | 1'4" |
| PRODUCTIVITY | ||
| Platform Capacity(unrestricted) | 260kg | 573 lbs |
| Platform Capacity(restricted) | 350kg | 772 lbs |
| Max. Platform Occupants | 2（unrestricted）/3(restricted) | |
| Turntable Rotation | 360° | |
| Drive Speed-Stowed | 5km/h | 3.1mph |
| Drive Speed-Raised | 0.8km/h | 0.5mph |
| Gradeability | 45% | |
| Max. Wind Speed | 12.5m/s | 28mph |
| Turning Radius-Inside | 3.5m | 11'6" |
| Turning Radius-Outside | 6.35m | 20'10" |
| Max. Slope | 4°/4° | |
| Tire Type | Solid | |
| Tire Models | 36*14-20 | |
| Ground Pressure, Tyres | 530.7 kPa | 77 psi |
| POWER | ||
| Power Source | Kubota 25kW/33.5hp | |
| Fuel Tank Capacity | 60L | 15.9 gal |
| HYDRAULIC SYSTEM | ||
| Hydraulic Oil Volume | 95L | 25.1 gal |
| WEIGHT | ||
| Machine Weight | 9300kg | 20503 lbs |
STANDARD FEATURES
Auto-leveling platform
Hydraulic rotating platform 180°
Full proportional joystick control
Descent alarm
Flashing beacons
Horn/Hour meter
Over-tilt protection system
Emergency stop button
Intelligent self-diagnosis function
Cylinder bellows
OTA remote upgrade
Dustproof components
Over-head anti-collision protection
Platform tool box
OPTIONAL
AC power to platform
Platform work light
Half-height mesh platform
Platform storage rack
Platform auxiliary guardrail
