The second generation of scissors lifts has been improved in various aspects, such as performance and design, which makes them even more convenient to maintain and safer to operate.
● Large lower control panel
● Entire range designed for Indoor and outdoor use
● Universal key components
● More convenient to maintain
● Optional lithium battery for the entire product range
| Models | S0607Ⅱ | S1932Ⅱ |
| Measurements | ||
| Work Height Max. | 7.8m | 25'7'' |
| A-Platform Height-Raised | 5.8m | 19' |
| B-Platform Length | 1.64m | 5'5'' |
| C-Platform Width | 0.73m | 2'5'' |
| D-Overall Length | 1.83m | 6' |
| E-Overall Width | 0.79m | 2'7'' |
| F-Overall Height-Guardrails Up | 2.16m | 7'1'' |
| G-Overall Height-Guardrails Down | 1.81m | 5'11'' |
| H-Extension Deck | 0.9m | 2'11'' |
| I-Wheelbase | 1.35m | 4'5'' |
| Ground Clearance(Stowed/Raised) | 78/26mm | 3''/1'' |
| Productivity | ||
| Max. Platform Occupants | 2 (in) /1 (out) | |
| Platform Capacity | 230kg | 510 lbs |
| Platform Capacity-Extension Deck | 120kg | 265 lbs |
| Drive Height | Full Height | |
| Gradeability-Stowed | 25% | |
| Min. Turning Radius | 1.7m | 5'7'' |
| Raise/Lower Speed | 16s /28s | |
| Brakes | Rear-wheel Brake | |
| Drive Mode | 4×2 | |
| Tire Type | Solid Non-marking | |
| Tire Size | 323*100mm | 12''x4'' |
| Ground Pressure, Tyres | 978 kPa | 141.8 psi |
| Power | ||
| Power Source | 24V (4x6V) 225Ah, FLA | |
| Power Source (Lithium Battery) | 24V 160Ah | |
| Hydraulic System | ||
| Hydraulic Oil Capacity | 9.5L | 2.1gal |
| Weight | ||
| Machine Weight(CE/ANSI) | 1610kg | 3549 lbs |
STANDARD FEATURES：
Indoor and outdoor rated
Proportional control
Foldable guardrail
Emergency stop device
Manual brake release
Emergency descent
Swing-out component tray
Pothole guard
Self-lock entry gate
Tilt alarm with lift cut-out
Overload sensing system
Descent alarm with flashing beacon
All motions alarm
Full-height drive
Intelligent diagnostic system
Solid non-marking tires
OPTIONAL：
AC power to platform
Anti-collision protection
Biodegradable hydraulic oil
Maintenance-free battery
Voice alarm system
Telematics
