l Lithium battery powered, low noise, zero-emission, maintenance-free, and high-capacity.
l Equipped with an innovative chassis expansion structure, and adopting magnetostrictive displacement sensor to realize high-accurate, simple and reliable control.
l Adopt three steering modes: front-wheel, crab and pivot steering, to meet the demand of operations in narrow space.
l Four synchronous telescopic booms, improving efficiency by over 30% than that of two-cylinder drive boom telescopic mode.
| MODELS | T38JE | T125JE |
| Measurements | Metric | Imperial |
| Work Height Max. | 40.2m | 131'11" |
| Platform Height Max. | 38.2m | 125'4" |
| Horizontal Outreach Max. | 23.5m | 77'1" |
| Platform Length | 2.44m | 8' |
| Platform Width | 0.9m | 2'11" |
| Stowed Length | 14.31m | 46'11" |
| Length-Transport (jib tucked) | 12.42m | 40'9" |
| Overall Width (outriggers stowed) | 2.49m | 8'2" |
| Overall Width (outriggers radius) | 4.01m | 13'2" |
| Stowed Height | 2.89m | 9'6" |
| Height-Transport | 2.92m | 9'7" |
| Wheelbase | 4.12m | 13'6" |
| Ground Clearance | 0.34m | 1'1" |
| PRODUCTIVITY | ||
| Max. Platform Occupants | 2 (unrestricted) / 3 (restricted) | |
| Platform Capacity (unrestricted) | 300kg | 661 lbs |
| Platform Capacity (restricted) | 450kg | 992 lbs |
| Turntable Rotation | 360°Continuous | |
| Drive Speed-Stowed | 5km/h | 3.1mph |
| Drive Speed-Raised | 0.4km/h | 0.25mph |
| Gradeability | 40% | |
| Max. Wind Speed | 12.5m/s | 28mph |
| Turning Radius-Inside (outriggers stowed) | 8.1m | 26'7" |
| Turning Radius-Outside (outriggers stowed) | 10.1m | 33'2" |
| Turning Radius-Inside (outriggers radius) | 3.1m | 10'2" |
| Turning Radius-Outside (outriggers radius) | 6.5m | 21'4" |
| Max.Slope | 5°/5° | |
| Tire Type | Foam-filled non-marking | |
| Tire Size | 445/50D 710 | |
| POWER | ||
| Power Source | 80V 604Ah | |
| HYDRAULIC SYSTEM | ||
| Hydraulic Oil Volume | 240 L | 63.4 gal |
| WEIGHT | ||
| Machine Weight | 20700 kg | 45635 lbs |
STANDARD FEATURES
Proportional control
Emergency stop button
Horn/Hour meter
Auto-leveling platform
Descent alarm
Anti-collision protection
Flashing beacons
Over-tilt protection system
Cylinder bellows
Telematics connector
Platform tool box
Overload sensing system
Oscillating axle
Intelligent diagnostic system
Platform control cover
Foam-filled non-marking tires
OPTIONAL
Telematics
Glazier kit
Auxiliary rail
AC power to platform
Half-height mesh platform
Solid tires
Solid non-marking tires
Foam-filled tires
Biodegradable hydraulic oil
