AR14J(AR45J)

LGMG AR Series articulating boom lifts are purpose built for outdoor construction and industrial applications. Simple and reliable design with industrial features make this machine easy to operate. A standard jib offers the ability to reach even the most hard to reach places.


l The oscillating axels and four-wheel drive deliver better gradeability on rough terrain.

l Proportional smooth driving, precise positioning and comfortable operation.

l Self-leveling platform together with hydraulic platform rotation delivers exceptional productivity.

l Swing out engine tray for easy access and maintenance.

l Intelligent self-diagnostic system for quick troubleshooting.


  • 16.09m(52.79ft)
    Work Height Max.
  • 230kg(510lbs)
    Platform Capacity
  • 2.31m(7.58ft)
    Machine Width
  • 7.67m(25.16ft)
    Horizontal Outreach
  • 7160kg(15785lbs)
    Machine Weight
ModelsAR14JAR45J
Measurements
Work Height Max.16.09m52'9''
Platform Height14.09m46'3''
Horizontal Outreach7.67m25'2''
Up and Over Height7.56m24'10''
A-Stowed Length6.77m22'3''
Lenth-Transport (jib tucked)5.49m18'
B-Stowed Width2.31m7'7''
C-Stowed Height2.17m7'1''
Height-Transport2.62m8'7''
D-Platform Size Length1.83m6'
E-Platform Size  Width0.76m2'6''
Platform Capacity230kg507 lbs
Wheelbase2.06m6'9''
Ground Clearance0.36m1'2''
Productivity
Max. Platform Occupants2
Drive Speed-Stowed6.1km/h3.8mph
Drive Speed-Raised0.8km/h0.5mph
Gradeability-Stowed45%
Turnable Rotation355°
Turning Radius-Inside1.94m6'4''
Turning Radius-Outside4.41m14'6''
Tires TypeRT Foam-filled
Tires Size                                 315/55D20
Ground Pressure, Tyres578.89 kPa84 psi
Power
Power Source

Deutz D2.9L4 36.4kw/48.8hp/

Kubota V2403 36kw/48.2hp

Fuel Tank Capacity65L17.2gal
Hydraulic System
Hydraulic Oil Capacity130L34.3gal
Weight

Machine Weight(CE/ANSI)

7160kg15785 lbs

Standard features

Proportional control

Tilt alarm with lift cut-out

Overload sensing system

Descent alarm with flashing beacon

Platform auto-leveling system

Emergency stop button

On-board diagnostic system

Oscillating axle

Four-wheel drive and break

Over tilt protection system

Anti-collision protection

Horn/Hour meter

Full-height drive

Platform tool box

Telematics connector

RT Foam-filled tires


Options

AC power to platform

Telematics

Foam-filled non-marking tires

Solid non-marking tires

Solid tires

Hydraulic generator kit

Cold weater package

Auiliary rail

Half-height mesh platform

Biodegradable hydraulic oil
